JEA-E93I
The JEA-E93I is a fanless embedded industrial BOX PC based on the NXP i.MX 93 ARM processor. It features a dual-core Cortex-A55 CPU, 2GB LPDDR4X memory, and 8/16/32GB eMMC storage. The system offers a wide range of interfaces, including HDMI, Ethernet, CAN, USB, and serial ports, with support for WiFi and 4G expansion. It operates in temperatures from -40°C to 70°C, runs Yocto Linux with a Qt environment, and supports multiple mounting options, making it ideal for various industrial applications.
- •
- Industrial grade NXP i.MX 93 SoC
- •
- 2x Cortex-A55 + 1x Cortex-M33 + 0.5 TOPS NPU
- •
- 2GB LPDDR4X + 8/16/32GB eMMC
- •
- HDMI 1.4 display up to 1080p60
- •
- 2x GbE, 2x CAN, 4x USB, up to 6x COM
- •
- On-board WiFi+BT module + Mini PCIe for 4G
- •
- Supports Yocto Linux+Qt build environment
- •
- Supports DIN Rail/wall/book-size mounting
- •
- Supports -40~70℃ operating temperature
System | SoC | NXP i.MX 9352 | |
CPU | Dual core Arm Cortex-A55 up to 1.5 GHz | ||
MCU | Arm Cortex-M33 up to 250 MHz | ||
NPU | 0.5 TOPS Neural Network performance | ||
Memory | On-board 2GB LPDDR4X | ||
Storage & Expansion | On-board 8GB/16GB/32GB eMMC 5.1 for OS 1x Micro SD slot for storage expansion or OS image flashing | ||
Video | Graphics Engine | NXP integrated 2D graphics acceleration | |
HW Video Codec | - | ||
Interface | 1x HDMI 1.4 Type-A up to 1080p60 | ||
Audio | Audio Codec | ES8336 | |
Interface | 1x 3.5mm Line out | ||
Network | Ethernet | 2x RJ45, 10/100/1000 Mbps, 4kV Surge protection | |
WiFi | On-board AW-CM358 WiFi 5 (802.11ac) + Bluetooth 5.2 module | ||
5G/4G | 1x Mini PCIe for 4G with Micro SIM slot | ||
I/O | Front I/O | 4x USB 2.0 Type-A (1 supports OTG for OS image flashing) 2x RS-232/485 by DB9 2x RS-232/TTL by DB9 | |
Side I/O | 2x RS-232/CAN by DB9 7x GPIO+1x ADC by DB9 (3.3V TTL level) 1x debug port by DB9 | ||
Other Features | Watchdog | Watchdog Timer & power on/off management | |
Real Time Clock | On-board RTC chip, battery-backed | ||
Security | NXP integrated EdgeLock secure enclave | ||
Power | Power Input | 12V DC-IN | Optional 9~36V DC-IN (typical 12/24V) with Reverse Polarity Protection |
Interface | 5.5x2.5mm DC Jack | 2-pole lockable terminal block | |
System Ctrl & Monitoring | 1x Power button, 1x Reset button 2x programmable LEDs | 1x Reset button 2x programmable LEDs (by pin header) | |
Mechanical | Dimensions | 187mm x 135mm x 54mm | |
Mounting | Wallmount, Bookmount, DIN Rail, VESA mount | ||
Software | OS Support | Yocto 4.2.3+Qt 6.5, Ubuntu (TBD), Android (TBD) | |
Boot Options | eMMC or SD, default to eMMC | ||
Environment | Operating Temp. | -40~70℃ | |
Storage Temp. | -40~85℃ | ||
Humidity | 10%~90% RH, non-condensing | ||
EMC & Safety | Compliance | IEC 61000-4-2 ESD level 3 (Contact ±6kV, Air ±8kV) IEC 61000-4-4 EFT level 4 (Power ±4kV, Ethernet ±2kV) | |
Certifications | CCC, CE Class B | ||
