S1600-8T-P
Suitable for Internet service providers (ISPs) and multi-system operators (Msos), providing more than GB of network bandwidth to home users. It is also the ideal gigabit access switch for SME, enterprise and campus networks.
- •
- Full Gigabit Ethernet switch
- •
- Non-network management
- •
- Plug and play
- •
- Supports IEEE802.3af/at functions
Performance | Switching capacity | 16Gbps |
Auto-negotiation | Support | |
Auto-MDI/MDIX | Support | |
Ports | RJ45 | 8*10/100/1000MBASE-T RJ45 Ports |
PoE | 802.3af/at | 8 ports |
Led | Port LED | Green: link/active Yellow:PoE |
Power supply | Inputrange | 54V/1.67A |
Connector | DC | |
System power consumption | 90W（PoE 80W) | |
Physical Parameters | Dimension (Wx D x H) mm | 158mm(L)×105mm(W)×27mm(H) |
Installation | Desktop installation | |
heat dissipation | Fanless natural heat dissipation | |
Environments | OperatingTemperature | -0~50℃(32~122 °F) |
StorageTemperature | -40~70℃(-40~158 °F) | |
Operating Humidity (non-condensing) | 10 to 95% (non-condensing) | |
Storage Humidity | 10 to 95% (non-condensing) | |
Certification | FCC ClassA | Support |
CE | Support | |
CB | Support | |
UL | Support |
