NS08R
Intel® Raptor Lake B760 chipset, with rich external interfaces, strong performance, widely used in home office, e-sports games, 3D rendering and so on.
- •
- Based on Raptor Lake B760&Alder lake H610 chip design
- •
- Chassis dimensions: (L)290 x (W)92 x (H)341mm
- •
- Two U-DIMM DDR5 modules supporting OC
- •
- Storage: 2 x M.2 2280/2242 SSD Port, 4 x SATA Gen3 Port
- •
- Expansion: 10 x USB2.0/3.0, 1 x PCIe4.0x16 slot, 1 x PCIe3.0x1 slot
- •
- Network: M.2 WIFI Slot, 1 x Gigabit network card, support network wake-up function
- •
- Display: 1 x VGA, 1 x HDMI
- •
- 6+1PHASE power supply, CPU power consumption 125W
With independent, controllable and innovative core technology and safe and reliable full-stack hardware capabilities, we provide customers with highly competitive hardware products and solutions.
Separate modular design
Base layer + up to 4 layer submodules
Pull out hard drive design
Free machine replacement, reduce maintenance time and cost
Modular i/o interface
Customized options to meet diverse peripheral needs
Multiple installation modes
Supports desktop and wall mounted
CPU | CPU | Intel® Raptor Lake-S Core™ Processors |
TDP | 65 W | |
System | Memory | Dual DIMM DDR5 Max. 64 GB |
Storage | 2 x M.2 Key M 2280/2242 Size For NVMe GEN4 X4 SSD | |
4 x SATA Gen3 Port | ||
OS | Windows11 | |
BIOS | AMI | |
WatchDog | Support | |
Auto Power On | Yes | |
Power Input | 220V AC IN, 200W/350W | |
Dimension | 290mm(L) x 92mm(W) x 341mm(H) | |
Operating Temp. | -5~45℃ | |
Operating Humidity | 10%~90% non-condensing | |
Storage Temp | -20~70℃ | |
Operating Humidity | 5%~95% non-condensing | |
Display | Graphic card | Intel® UHD Graphics |
Multi displays | Support 2 displays | |
Interface | 1 x HDMI1.4 | |
1 x VGA | ||
Network | Lan IC | RTL8111H |
Lan Interface | 10/100/1000Mbps | |
Lan Connector | 1 x RJ45 Ports | |
Wireless Type | M.2 Key E 2230 Module | |
Wireless Interface | WiFi6E/BT5.1 Module | |
I/O interface | Serial Port | N/A |
USB | Front: 2 x USB2.0, 2 x USB3.2 Gen1 | |
Rear: 2 x USB2.0, 4 x USB3.2 Gen1 | ||
Button | 1 x PowerButton | |
AUDIO | Front: 1 x Mic in, 1 x Line out | |
Rear: 1 x Line out, 1 x Line in, 1 x Mic in | ||
Expansion | 1 x PCI Express4.0 x16 slot | |
1 x PCI Express3.0 x1 slot | ||
POWER | 1 x 220V ATX Connector |
