PAC-3010
PAC-3010 is a powerful Programmable Automation Controller featuring an Intel® Celeron® Elkhart Lake J6412 processor, offering high performance and a wide range of interfaces. It supports up to 32GB of DDR4 memory and is equipped with various communication ports including HDMI, Ethernet, EtherCAT, USB, and serial ports. The system is highly expandable, supports multiple storage options, and is designed for low power consumption and wide temperature operation, making it suitable for diverse industrial automation and control applications.
- •
- Intel J6412 SoC
- •
- 1×SODIMM DDR4 Memory, up to 32GB
- •
- 1xHDMI
- •
- 2xENET, 1xECAT
- •
- 2xUSB3.0, 2xUSB2.0
- •
- 2x RS485, 1x RS232
- •
- 1x mSATA，1x mPCIe
- •
- MB:2DI&2DO, IO Card:16DI&12DO
- •
- Supports LCD modules with MCU
- •
- DC IN 24V. Electrolytic capacitor inside
System | Processor | Intel® Celeron® Elkhart Lake J6412 |
Chipset | Intel® Elkhart Lake SoC | |
BIOS | AMI UEFI BIOS | |
Memory | 1xDDR4 3200MHz SO-DIMM, up to 32GB | |
OS | Windows10, Linux | |
I/O interface | USB | 2xUSB 3.0, 2xUSB 2.0, 2x USB2.0(via pin header） |
Serial | 2xRS485, 1xRS232(can change to RS485) ， Phoenix terminal | |
DI/DO | DI*2 (With optocoupler isolation) ， compatible with NPN/PNP; DO*2 (With optocoupler isolation) ， NPN output | |
LED | 1xPower, 1xHDD | |
Expansion | Mini-PCIe | 1x Mini-PCIe |
Graphics
| Graphics Processor | Intel®UHD Graphics 630 |
Interface | 1xHDMI,up to 4096*2160@24Hz | |
Storage | Storage Device | 1xmSATA |
Ethernet | LAN | 2x ENET( Intel I226V& I210AT), 1x ECAT(I210AT) |
Display | LCD | Monochrome 128x64 Dot Matrix Display ， With up, down, back and confirm buttons |
Power | Power Input | DC IN 24V, Electrolytic capacitor inside ， 250ms Power-off Retention |
Power Interface | 3-Pole Phoenix DC plug in | |
Others | IO Card | PAC-3010 without IO Card PAC-3011with IO Card： 16 bit DI with optocoupler isolation ， compatible with NPN/PNP 12 bit NPN DO withdigital isolation Reserve 1xI210 network port (without parts) |
Mechanical | Dimensions（WxHxD) | PAC-3010: 59*210*150 mm(without bracket), 59*245*150 mm(with bracket)； PAC-3011: 74*210*150 mm(without bracket), 74*245*150 mm(with bracket) |
Weight | 2.1KG | |
Mounting | Wall-mounting | |
Environment | Operating Temp. | -10℃~55℃ |
Storage Temp. | -40~85℃ | |
Humidity | 95%@40℃ (non-condensing) | |
Shock | With SSD: 15G, IEC 60068-2-27, half sine, 11ms duration | |
Vibration | With SSD:2Grms, IEC 60068-2-64, random ， 5~500Hz ， 1 hr/axis |
